Description:
Function:
1.Ergonomic design;
2.Adjustable backrest and headrest;
3.Seat height may be angle adjusted;
4.Seats can be moved back and forth;
5.Folding / angle-adjustable comfortable seat armrest;
6.Seat can rotated 360 degrees, multi-point positioning;
7.Foot pedal height adjustable / folding;
8.Column can be vertically lifting
Material：
1.Slide rail and positioning base uses the high strength aluminum alloy, inside and outside decorative mosaic made of stainless steel;
2.lifting column with steel、stainless steel synthesis;
3.The seat lifting and tilting, move back and forth, back angle adjusting are used in steel structure;
4. The seat back and the seat cushion adopts the steel inner core and PU cold foam forming disposable sponge synthesis, outsourcing leather or cloth;
5. Steel structure for the footrest;6. Pneumatic lifting core components pneumatic bar the use of German imports of Stabilus
Function data：
1.Upper part of the seat can be moved back and forth of120mm,height adjustment 60mm, seat inclination angle range of ±12°;
2. Seat backrest with adjustable angle of 85°-150°, the headrest adjusted up and down 50mm, handrest multi-point positioning control;
3. The seat of pneumatic lifting regulating range 0-150mm；
4.The seat can rotate 360°and locked ,4-point positioning control;
5.Seat rail slide in 0-4000mm mobile,500mm rail width and depth 28mm
6. Seat pedal can rotate 90° and regression;
7.Seat can bear more than 150FT.LB torsion, reached AD grade standard
